Assembly and installation
5.5 Electrical installation
NOTE
Risk of material damage to the RollerDrive and/or the RollerDrive cables.
¾ Never operate the RollerDrive with an alternating current (AC), as this can result in irreparable damage to
the device.
¾ Do not expose the RollerDrive connector to excessively high tensile or pressure loads. Bending the
RollerDrive cables or sliding the attachment nut on too forcefully can damage the insulation of the cables,
which can lead to the failure of the RollerDrive.
¾
pressure loads.
¾ Permissible bending radii: Simple bending 25 mm, multiple bending 50 mm.
¾ The RollerDrive cable is not suitable for drag chains.
¾ Connect the RollerDrive connector to the corresponding connection of the Interroll control.
If no Interroll control is used, an adapter cable must be used to connect the RollerDrive to the control (for
pin assignment, see „RollerDrive connector“ on page 20
the warranty.
NOTE
Possible damage to the RollerDrive.
Pins 1 and 3 are not secured against reverse polarity
¾ Ensure that the polarity is correct.
