25 of 42
Assembly and installation
5 Assembly and installation
5.1 Warning notices for installation
WARNING
Risk of crushing due to rotating parts.
¾
¾
PolyVee belt or round belt.
¾
NOTE
An improper approach to installing the RollerDrive can lead to material damage or reduce the service life of the
RollerDrive.
¾ To preserve the interior of the RollerDrive, do not allow the RollerDrive to fall or for it to be used in an
improper fashion.
¾ Check each RollerDrive before assembly for any visible damage.
¾ To prevent the inner connections from being damaged, do not hold, carry or secure the RollerDrive by the
cable.
¾
¾ Pay attention to the correct tightening torque of the RollerDrive hexagonal nut to prevent the shaft in the
„Securing the RollerDrive in the side
).
¾ Do not twist the RollerDrive cable.
