Product information
3.5 Technical specications
Rated voltage 24 V DC, protected extra-low voltage (PELV)
Voltage range 18 to 28 V DC
Idle current 0.4 A
Rated current Approx. 2 A
1)
Starting current Approx. 4 A
1)
Switching threshold, signal input
"Rotational direction"
Safe "High": U > 7 V DC
Safe "Low": U < 4 V DC
Mechanical power 32 W
Maximum residual ripple of the
power supply
3%
Maximum noise level
(mounted)
55 dB(A)
2)
Protection rate IP54 or IP66
Ambient temperature in operation EC310:
EC310 DF:
EC310 IP66:
0 °C to +40 °C
-30 °C to 0 °C
+5 °C to +40 °C
Ambient temperature for
transport and storage
-30 °C to +75 °C
Altitude of installation site Max. 1000 m
3)
All data applies for an ambient temperature of 20 °C.
From 25 °C, a derating factor must be taken into account.
1)
The actual current course is dependent on the circumstances of the application, such as conveyor weight, number of
connected rollers, etc.
2)
3)
Estimated derating: 5% from 1500 m, 10% from 2000 m.
