Interroll RollerDrive EC310 User Manual

Version 3.1 (02/2019)
Translation of the original operating manual
17 of 42
Product information
3.4 Product identication
The following information is required to identify the RollerDrive:
Information Possible value Own value
RollerDrive
Rating plate
Motor type
Gear ratio
Serial number
Tube diameter 50 mm, 51 mm
Tube material Stainless steel
Zinc-plated steel
Chromium-plated steel
Aluminium
Tube sleeve PVC hose 2 mm, 5 mm
PU hose 2 mm
Rubber coating 2–5 mm
Tapered elements 1.8°, 2.2°
Roller installation length Installation length
Drive element PolyVee belt
Round belt:
Groove
Round belt head
Toothed belt
Attachment on the non-cable side Hexagonal spring shaft
Internal thread attachment
Hexagonal spring shaft, conical
(See „Dimensions of the bearing
housings on the non-cable side“ on
page 21)
