Invacare MK6i - 9 Seating Systems; Standard and Kontur Seats; Adjusting the Seat Tilt

53
9 Seating systems
9.1 Standard and Kontur Seats
Kontur Seat
9.1.1 Adjusting the seat tilt
Manual adjustment:
• Manual adjustment:
• Loosen the knurled nut (1) and screw downwards.
• Turn the threaded adjustment sleeve (2) counterclockwise = lift the front
edge of the seat.
• Turn the threaded adjustment sleeve (2) clockwise = lower the front edge
of the seat.
• Re-tighten the knurled nut (1).
