10.1.1.2 Footrest: Adjusting the Angle
Warning: Danger of Injury if footrest or legrest is incorrectly adjusted!
• Before and during each drive, always make sure there is sufficient clearance between the
legrest (or footrest) and the ground, as well as the castors!
• Loosen the screw that allows the angle to be adjusted (1).
• It the footrest still cannot be moved after loosening the screw, position a
metal pin in the hole on the side (2) and tap it lightly with a hammer. This
releases the clamping mechanism inside the footrest. If necessary, repeat
this procedure from the other side of the footrest.
• Adjust to the desired angle.
• Tighten the screw again.
