10.2.2.3 Manually adjustable legrest: Angle Adjustment
Warning: Danger of injury by moving parts!
• Do not place fingers in the area between the upper and lower parts of the legrest!
• Adjust the legrest upward by pulling it up to the desired angle (1).
• To lower the legrest, hold it by the footplate, pull the adjustment lever on
the side (2) and slowly lower the legrest (3).
NOTE:
After letting the adjustment lever go, the legrest is locked at the desired angle.
