Invacare MK6i - Width Adjustment of the Legrests (Option)

90
10.3 Width Adjustment of the Legrests (Option):
• The screws that allow adjustment of the width are located under the seat.
Position of the clamping
lever
NOTE:
The lights must not be obscured by the legrests.
If necessary, they must be positioned farther toward the outside.
To do this, use the different holes of the mounting plates.
• Loosen the screws (1) using a 4 mm Allen Key.
• Pull the legrest mounting brackets (2) outwards until the desired width is
reached.
• Tighten the screws again.
