Adjustment by metal plate with holes (available as an option for
Standard Seats)
• The angle of the backrest is determined by the metal plate with screw-
holes, which attaches the backrest to the frame.
• The angle can be changed by selecting different combinations of holes
between 0°, 5°, 10° or 15° (see drawing).
Position of the metal
plate
• Remove the screws that hold the backrest frame on both sides using a 13
mm open-end spanner.
• Select the correct holes for the desired angle using the drawing at right.
• Re-fasten the backrest frame using the hole combination selected.
Metal plate with holes
NOTE:
To make it easier to re-position the screws that hold the backrest, it may be held in place by a
second person.
