4ElectricalInstallation
4. ElectricalInstallation
4.1. GroundingtheDrive

Thismanualisintendedasaguideforproperinstallation.InvertekDrivesLtdcannotassumeresponsibilityforthecompliance
orthenon‐compliancetoanycode,national,localorotherwise,fortheproperinstallationofthisdriveorassociated
equipment.Ahazardofpersonalinjury and/orequipmentdamageexistsifcodesareignoreddu
ringinstallation.

ThisOptidrivecontainshighvoltagecapacitorsthattaketimetodischargeafterremovalofthemainsupply.Beforeworkingon
thedrive,ensureisolationofthemainsupplyfromlineinputs.Waitten(10)minutesforthecapacitorstodischargetosafe
voltagelevels.Failuretoobservethisprecautioncouldresultinse
verebodilyinjuryorlossoflife.

Onlyqualifiedelectricalpersonnelfamiliarwiththeconstructionandoperationofthisequipmentandthehazardsinvolved
shouldinstall,adjust,operate,orservicethisequipment.Readandunderstandthismanualandotherapplicablemanualsin
theirentiretybeforeproceeding.Failuretoobservethisprecautioncouldresultinseverebodilyinjuryorlossoflif
e.
4.1.1. RecommendedinstallationforEMCcompliance.

