Invertek Drives OPTIDRIVE P2 Series User Manual

OptidriveODP‐2UserGuideRevision1.30

www.invertekdrives.com
9

2 GeneralInformationandRatings
2.3. Drivemodelnumbers–IP55
Mechanicaldimensionsandmountinginformationareshownfromsection3.4.2onpage122.
Electricalspecificationsareshowninsection10.2onpage47.
200‐240V±10%‐ 3PhaseInput
kWModelNumber kW HPModelNumber HP OutputCurrent(A) FrameSize
ODP‐2‐42055‐3KF4N‐SN
*
 5.5 ODP‐2‐42075‐3HF4N‐SN
*
 7.5 24 4
ODP‐2‐42075‐3KF4N‐SN
*
 7.5 ODP‐2‐42100‐3HF4N‐SN
*
10 39 4
ODP‐2‐42110‐3KF4N‐SN
*
 11 ODP‐2‐42150‐3HF4N‐SN
*
 15 46 4
ODP‐2‐52150‐3KF4N‐SN
*
 15 ODP‐2‐52020‐3HF4N‐SN
*
 20 61 5
ODP‐2‐52185‐3KF4N‐SN
*
 18.5 ODP‐2‐52025‐3HF4N‐SN
*
25 72 5
ODP‐2‐62022‐3KF4N‐SN
*
 22 ODP‐2‐62030‐3HF4N‐SN
*
 30 90 6
ODP‐2‐62030‐3KF4N‐SN
*
 30 ODP‐2‐62040‐3HF4N‐SN
*
 40 110 6
ODP‐2‐62037‐3KF4N‐SN
*
 37 ODP‐2‐62050‐3HF4N‐SN
*
50 150 6
ODP‐2‐62045‐3KF4N‐SN
*
 45 ODP‐2‐62060‐3HF4N‐SN
*
 60 180 6
ODP‐2‐72055‐3KF4N‐SN
*
 55 ODP‐2‐72075‐3HF4N‐SN
*
 75 202 7
ODP‐2‐72075‐3KF4N‐SN
*
 75 ODP‐2‐72100‐3HF4N‐SN
*
100 248 7
380‐480V±10%‐3PhaseInput
kWModelNumber kW HPModelNumber HP OutputCurrent(A) FrameSize
ODP‐2‐44110‐3KF4N‐SN
*
 11 ODP‐2‐44150‐3HF4N‐SN
*
15 24 4
ODP‐2‐44150‐3KF4N‐SN
*
 15 ODP‐2‐44200‐3HF4N‐SN
*
 20 30 4
ODP‐2‐44185‐3KF4N‐SN
*
 18.5 ODP‐2‐44250‐3HF4N‐SN
*
 25 39 4
ODP‐2‐44220‐3KF4N‐SN
*
 22 ODP‐2‐44300‐3HF4N‐SN
*
30 46 4
ODP‐2‐54300‐3KF4N‐SN
*
 30 ODP‐2‐54040‐3HF4N‐SN
*
 40 61 5
ODP‐2‐54370‐3KF4N‐SN
*
 37 ODP‐2‐54050‐3HF4N‐SN
*
 50 72 5
ODP‐2‐64045‐3KF4N‐SN
*
 45 ODP‐2‐64060‐3HF4N‐SN
*
60 90 6
ODP‐2‐64055‐3KF4N‐SN
*
 55 ODP‐2‐64075‐3HF4N‐SN
*
75 110 6
ODP‐2‐64075‐3KF4N‐SN
*
 75 ODP‐2‐64120‐3HF4N‐SN
*
 120 150 6
ODP‐2‐64090‐3KF4N‐SN
*
 90 ODP‐2‐64150‐3HF4N‐SN
*
150 180 6
ODP‐2‐74110‐3KF4N‐SN
*
 110 ODP‐2‐74175‐3HF4N‐SN
*
175 202 7
ODP‐2‐74132‐3KF4N‐SN
*
 132 ODP‐2‐74200‐3HF4N‐SN
*
 200 240 7
ODP‐2‐74160‐3KF4N‐SN
*
 160 ODP‐2‐74250‐3HF4N‐SN
*
250 302 7
480‐525V±10%‐ 3PhaseInput
kWModelNumber kW HPModelNumber HP OutputCurrent(A) FrameSize
ODP‐2‐75132‐3K04N‐SN
*
 132 185 7
ODP‐2‐75150‐3K04N‐SN
*
 150 205 7
ODP‐2‐75185‐3K04N‐SN
*
 185   255 7
ODP‐2‐75200‐3K04N‐SN
*
 200 275 7
500‐600V±10%‐ 3PhaseInput
kWModelNumber kW HPModelNumber HP OutputCurrent(A) FrameSize
ODP‐2‐46185‐3KF0N‐SN
*
 18.5 ODP‐2‐46250‐3HF0N‐SN
*
 25 28 4
ODP‐2‐46220‐3KF0N‐SN
*
 22 ODP‐2‐46300‐3HF0N‐SN
*
30 34 4
ODP‐2‐56300‐3KF0N‐SN
*
 30 ODP‐2‐56400‐3HF0N‐SN
*
 40 43 5
ODP‐2‐56370‐3KF0N‐SN
*
 37 ODP‐2‐56050‐3HF0N‐SN
*
 50 54 5
ODP‐2‐56450‐3KF0N‐SN
*
 45 ODP‐2‐56060‐3HF0N‐SN
*
60 65 5
ODP‐2‐66055‐3KF0N‐SN
*
 55 ODP‐2‐66075‐3HF0N‐SN
*
 75 78 6
ODP‐2‐66075‐3KF0N‐SN
*
 75 ODP‐2‐66100‐3HF0N‐SN
*
 100 105 6
ODP‐2‐66090‐3KF0N‐SN
*
 90 ODP‐2‐66125‐3HF0N‐SN
*
125 130 6
*Note:Thefinaltwocharactersofthemodelnumberrelatetoavailablefactorybuildoptionsasfollows
‐SN StandardSevenSegmentLEDDisplay,standardPCBcoating
‐SC StandardSevenSegmentLEDDisplay,additionalPCBconformalcoating
‐TN OLEDTextDisplayDisplay,standardPCBcoating
‐TC OLEDTextDisplay,addi
tionalPCBconformalcoating


