OptidriveODP‐2UserGuideRevisions1.30
48
www.invertekdrives.com
10TechnicalData
10.2.3. 380–480Volt(+/‐10%),3PhaseInput,3PhaseOutput
Power
Rating
Nominal
Input
Current
Fuseor
MCB(TypeB)
Supply
Cable
Size
Rated
Output
Current
Motor
Cable
Size
Maximum
Motor
CableLength
Recommended
Brake
Resistance
kW HP A NonUL UL mm AWG/kcmil A mm AWG m ftΩ
0.75 1 2.4 10 6 1.5 14 2.2 1.5 14 100 330 400
1.5 2 5.1 10 10 1.5 14 4.1 1.5 14 100 330 200
2.2 3 7.5 10 10 1.5 14 5.8 1.5 14 100 330 150
4 5 11.2 16 15 2.5 14 9.5 1.5 14 100 330 100
5.5 7.5 19 25 25 4 10 14 1.5 12 100 330 75
7.5 10 21 32 30 6 10 18 2.5 10 100 330 50
11 15 28.9 40 40 10 8 24 4 10 100 330 40
15 20 37.2 50 50 16 8 30 6 8 100 330 22
18.5 25 47 63 60 16 6 39 10 8 100 330 22
22 30 52.4 80 70 25 4 46 10 6 100 330 22
30 40 63.8 80 80 25 4 61 16 4 100 330 12
37 50 76.4 100 100 35 3 72 25 3 100 330 12
45 60 92.2 125 125 50 1 90 35 2 100 330 6
55 75 112.5 160 150 70 1/0 110 50 1/0 100 330 6
75 100 153.2 200 200 95 3/0 150 70 3/0 100 330 6
90 150 183.7 250 250 120 4/0 180 95 4/0 100 330 6
110 175 205.9 300 300 185 300 202 120 250 100 330 6
132 200 244.5 400 350 185 350 240 150 350 100 330 6
160 200 307.8 400 400 2x95 600 302 2x70 500 100 330 6
200 200 370 500 500 2x150 750 370 2x95 750 100 330 2
250 200 450 600 600 2x150 1250 450 2 x120 1250 100 330 2
Note
• Ratingsshownaboveapplyto40°CAmbienttemperature.Forderatinginformation,refertosection10.4.1
• Operationwithsinglephasesupplyispossible,with50%deratingoftheoutputcurrentcapacity
• Themaximummotorcablelengthstatedappliestousingashieldedmotorcable.Whenusinganunshieldedcable,th
emaximumcable
lengthlimitmaybeincreasedby50%.WhenusingtheInvertekDrivesrecommendedoutputchoke,themaximumcablelengthmaybe
increasedby100%
• ThePWMoutputswitchingfromanyinverterwhenusedwithalongmotorcablelengthcancauseanincreaseinthevoltageatth
emotor
terminals,dependingonthemotorcablelengthandinductance.Therisetimeandpeakvoltagecanaffecttheservicelifeofthemotor.
InvertekDrivesrecommendusinganoutputchokeformotorcablelengthsof50mormoretoensuregoodmotor servicelife
• ForULcompliantinsta
llation,useCopperwirewithaminimuminsulationtemperatureratingof70°C,ULClassCCorClassJFuses
• DatavaluesshowninItalicsareprovisional
10.2.4. 480–525Volt(+/‐10%),3Phaseinput,3PhaseOutput
Power
Rating
Nominal
Input
Current
Fuseor
MCB(TypeB)
Supply
Cable
Size
Rated
Output
Current
Motor
Cable
Size
Maximum
Motor
CableLength
Recommended
Brake
Resistance
kW HP A NonUL UL mm AWG/
kcmil
A mm AWG m ftΩ
132 184 250 250 120 4/0 185 95 250 100 330 6
150 198.7 250 250 120 250 205 120 300 100 330 6
185 246.6 400 350 185 350 255 185 400 100 330 6
200 255.9 400 350 2x95 400 275 185 500 100 330 6
Note
• Ratingsshownaboveapplyto40°CAmbienttemperature.Forderatinginformation,refertosection10.4.1
• Themaximummotorcablelengthstatedappliestousingashieldedmotorcable.Whenusinganunshieldedcable,themaximumcable
lengthlimitmaybeincreasedby50%.WhenusingtheInvertekDrivesrecommendedoutp
utchoke,themaximumcablelengthmaybe
increasedby100%
• ThePWMoutputswitchingfromanyinverterwhenusedwithalongmotorcablelengthcancauseanincreaseinthevoltageatthemotor
terminals,dependingonthemotorcablelengthandinductance.Therisetimeandpeakvoltageca
naffecttheservicelifeofthemotor.
InvertekDrivesrecommendusinganoutputchokeformotorcablelengthsof50mormoretoensuregoodmotor servicelife
• ForULcompliantinstallation,useCopperwirewithaminimuminsulationtemperatureratingof70°C,ULClassCCorClas
sJFuses
• DatavaluesshowninItalicsareprovisional
