INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Communication protocol
.106.
Higher byte of 0004H 13H
Low byte of 0004H 88H
High byte of 0005H 05H
Low byte of 0005H DCH
Low byte of CRC 7CH
High byte of CRC 54H
END T1-T2-T3-T4 (transmission time of 3.5 bytes)
10.7.2 ASCII mode, read 2 data from 0004H:
The request command is:
START ‘:’
Node address
‘0’
‘1’
Command
‘0’
‘3’
High byte of start address
‘0’
‘0’
Low byte of start address
‘0’
‘4’
High byte of data number
‘0’
‘0’
Low byte of data number
‘0’
‘2’
LRC CHK Hi ‘F’
LRC CHK Lo ‘6’
END Lo CR
END Hi LF
The reply is
START ‘:’
Node address
‘0’
‘1’
Command
‘0’
‘3’
Returned byte number
‘0’
‘4’
