CHV180 series frequency inverter special for elevator Wiring
.13.
4.1 Connections of peripheral devices
Figure 4.1 Connections of peripheral devices.
4.2 Terminal configuration
4.2.1 Main circuit terminals (400VAC)
(+)
PB
(-)
R S T U V W
POWER MOTOR
Figure 4.2 Main circuit terminals (4~5.5kW)
(+)
PB
(-)
R S T U V W
POWER MOTOR
Figure 4.3 Main circuit terminals (7.5~15kW).
