CHV180 series frequency inverter special for elevator Detailed function description
.77.
Function
Code
Name Description
Setting
Range
Factory
Setting
Pb.06
AD detection
value of
encoder C
phase
0~1024
Pb.07
AD detection
value of
encoder D
phase
0~1024
The parameters display the sampling value of present encoder signal, the function
codes are used to correct zero-bias of encoder (P4.08,P4.09) when the synchronizer
performs static autotuning.
Function
Code
Name Description
Setting
Range
Factory
Setting
Pb.08~Pb.09
Reserved Reserved
6.13 PC Group –Load starting parameters
Function
Code
Name Description
Setting
Range
Factory
Setting
PC.00
No weighting
compensation
enable
0:disable
1:Enable
0~1 0
PC.01
Load
compensation
time
0.000~5.000s 0.000~5.000
0.500s
During the load compensation time, speed loop ASR PI selects PC.03 and PC.04, and
position loop PC.05 and PC.06 are effective. The parameter starts timing from
receiving running command, and it is generally set to be zero speed holding time.
Function
Code
Name Description
Setting
Range
Factory
Setting
PC.02
Load
compensation
lower time
0.000~5.000s 0.000~5.000s
0.300s
The parameter is the transition time of ASR from PC.03 and PC.04 to P3.00 and
