CHV180 series frequency inverter special for elevator Appendix C
.127.
Appendix C: Specification of accessories
C.1 Specifications of breaker, cable, contactor and reactor
C.1.1 Specifications of breaker, cable and contactor
Model No.
Circuit
breaker
(A)
Input/output cable
(mmP
2
P
)
(Coppery wire)
Rated current of
contactor (A)
CHV180-004G-4 25 4 16
CHV180-5R5G-4 25 4 16
CHV180-7R5G-4 40 6 25
CHV180-011G-4 63 6 32
CHV180-015G-4 63 6 50
CHV180-018G-4 100 10 63
CHV180-022G-4 100 16 80
CHV180-030G-4 125 25 95
C1.2 Specifications of AC input/output and DC reactor
Model No.
AC Input reactor
AC Output reactor
DC reactor
Current
（A）
Inductance
（mH）
Current
（A）
Inductance
（mH）
Current
（A）
Inductance
（mH）
CHV180-004G-4 10 1.5 10 0.6 12 6.3
CHV180-5R5G-4 15 1.0 15 0.25 23 3.6
CHV180-7R5G-4 20 0.75 20 0.13 23 3.6
CHV180-011G-4 30 0.60 30 0.087 33 2
CHV180-015G-4 40 0.42 40 0.066 33 2
CHV180-018G-4 50 0.35 50 0.052 40 1.3
CHV180-022G-4 60 0.28 60 0.045 50 1.08
CHV180-030G-4 80 0.19 80 0.032 65 0.80
Note: The machine of E, F and G are embedded with DC reactors.
C.1.3 Specification of input filter and output filter
Inverter capacity (kW) Input filter model Output filter model
CHV180-004G-4 FLT-P04016L-B FLT-P04016L-B
CHV180-5R5G-4 FLT-P04016L-B FLT-P04016L-B
CHV180-7R5G-4 FLT-P04032L-B FLT-P04032L-B
