CHV180 series frequency inverter special for elevator Operation
.26.
5.1.3.2 Unit indicator light description
Unit indicator Description
Hz Frequency unit
A Current unit
V Voltage unit
RPM Rotating speed unit
% Percentage
Hz+V m/s
5.1.3.3 Digital display
Have 5 digit LED , which can display all kinds of monitoring data and alarm codes such
as reference frequency, output frequency and so on.
5.2 Operation process
5.2.1 Parameter setting
Three levels of menu are:
Function code group (first- class);
Function code (second- class);
Function code value (third- class).
Remarks:
Pressing both the PRG/ESC and the DATA/ENT can return to the second-class menu
from the third-class menu. The difference is: pressing DATA/ENT will save the set
parameters into the control panel, and then return to the second-class menu with
shifting to the next function code automatically; while pressing PRG/ESC will directly
return to the second-class menu without saving the parameters, and keep staying at
the current function code.
To Next Page
