CHV180 series frequency inverter special for elevator Detailed function description
.66.
This value can inform the state of digital input signal at fault.
The state of the current fault input terminal is decimal number. Display the state of all digital
input terminals at the latest fault, the sequence is:
BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
RO3 RO2 RO1 HDO Y2 Y1
1 indicates corresponding output terminal is ON, while 0 indicates OFF.
Note: This value is displayed as decimal.
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.21 Reserved 0~65536 0~65536
0
P7.22 Reserved 0~65536 0~65536
0
6.9 P8 Group --Enhanced function
Function
Code
Name Description
Setting
Range
Factory
Setting
P8.00
Analog weigh
signal input
selection
0: No function
1: AI1
2: AI2
0~2 0
This parameter can improve start comfortable of elevator.
Note: This analog signal can’t use the same analog input source with speed
command selection (P0.03)
Function
Code
Name Description
Setting
Range
Factory
Setting
P8.01
Pre-torque
offset
0.0~100.0% 0.0~100.0
30.0%
P8.02 Drive side gain
0.000~7.000 0.000~7.000 1.000
P8.03 Brake side gain
0.000~7.000 0.000~7.000 1.000
When elevator is running, the start comfortable is improved by pre-torque
compensating difference value of elevator car and counterpoise. Only when P8.00 isn’t
set to be 0, pre- torque compensation will be available. The detailed way and size are
as follow:
Direction running
Comparison
Pre-torque compensation
value
Up running
Car > counterpoise P8.02*(car - P8.01)
Car < counterpoise P8.03*( car - P8.01)
