CHV180 series frequency inverter special for elevator Extension card
.83.
Figure 7.5 Dimension of I/O extension card.
(2) Sketch map of terminal compositor
7.2.3 Installation of I/O extension card for CHV180
Figure 7.6 Installation of of I/O extension card and PG card.
7.3 Description of asynchronous motor PG card
7.3.1 Model and specifications
7.3.1.1 The asynchronous PG card of CHV100 series inverters is PN000PGWX, below
is the specification table:
Terminal name Specification
12V and COM1
Power supply of the encoder
Max. output current: 300mA
Operation panel
Control terminal
PG Extension
Main circuit terminal
Main circuit cable inlet
Control cable inlet
CHARGE light
I/O Extension card
Insallation hole

INVT CHV180-004G-4 Specifications

General

Brand	INVT
Model	CHV180-004G-4
Category	Inverter
Language	English
