CHV180 series frequency inverter special for elevator Detailed function description
.55.
Function
Code
Name Description
Setting
Range
Factory
Setting
P5.18 AI2 lower limit
0.00V~10.00V 0.00~10.00
0.00V
P5.19
AI2 lower limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
0.0%
P5.20 AI2 upper limit
0.00V~10.00V 0.00~10.00
5.00V
P5.21
AI2 upper limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
100.0%
P5.22
AI2 filter time
constant
0.00s~10.00s 0.00~10.00
0.10s
Please refer to description of AI1.
The setting of AI2 function is the same as that of AI1. Analog AI2 can support 0~10V or
0~20mA input. When AI2 selects 0~20mA, the corresponding voltage of 20mA is 5V.
CHV180 series inverters have 2 ways of analog input.
6.7 P6 Group -- Output terminals
CHV180 series inverters have 1 way of multi-function digital input terminal, 2 way of
multi-function relay output terminals and 1 way of HDO terminal (can be selected as high
speed pulse output terminal and analog output terminal) as the standard configuration. If
it is necessary to add relay output terminal and analog output terminal, it is available to
select multi-function input/output extension card.
The multi-function input/output extension card has 1 way of multi-function relay output
terminal and 1 way of multi-function analog output terminal.
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.00
HDO output
selection
0: High-speed pulse output
1: Open collector output
0~1 0
0: Open collector High-speed pulse output: The maximum pulse frequency is 50.0 kHz.
Please refer to description of P6.09.
1: Open collector output: Please refer to description of P6.03.
Note: HDO terminal is for programmable multiplexing output.
