INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Detailed function description
.56.
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.01
Y1 output
selection
Open-collector output 0~20 1
P6.02
Y2 output
selection
Open-collector output 0~20 0
P6.03
HDO open
collector
output
selection
Open-collector output 0~20 0
P6.04
Relay 1 output
selection
Relay output 0~20 4
P6.05
Relay 2 output
selection
Relay output 0~20 5
P6.06
Relay 3 output
selection
Relay output 0~20 0
Open collector output functions are indicated in the following table:
Setting
Value
Function Description
0 No output No function.
1
Elevator
running(LR)
ON: During run.
2 Up running ON: During running up.
3 Down running ON: During running down.
4 Fault output ON: When fault occur.
5
Zero speed
running
ON: When the output speed and setting speed are
zero during running.
6 Running is ready
ON: Inverter is ready (no fault, power is ON).
7
Holding-brake
control
When the P8.04 setd to be 1,it will output the brake
signal
ON: take off the brake.
OFF: hold the brake.
8
Contactor
control
ON: close the contactor.
OFF: open the contactor.
