CHV180 series frequency inverter special for elevator Detailed function description
.57.
Setting
Value
Function Description
9
Frequency
reached
Please refer to the description of P6.24.
10 FDT reached Please refer to the description of P6.22 and P6.23.
11
Elevator running
1 (LR1)
ON: From brake-releasing delay finished to closing
brake finished.
12
Holding-brake
output
ON: From brake-closing delay finished to stop
13~20
Reserved Reserved
Note: Multi-function output terminal 11 and 12 are mainly used when: when the
barking is used external control, it will inform the control system to close or release
the braking. Please refer to figure 8.2 for the detailed logic.
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.07
AO1 output
selection
0~14 0~14 0
P6.08
AO2 output
selection
0~14 0~14 0
P6.09
HDO open
collector high
speed pulse
output
selection
0~14 0~14 0
The standard output of AO1 and AO2 is 0~10V/0~20mA, which can be selected by J19
jumper wire. The range of P6.09 is from 0 kHz to 50.kHz.
AO/HDO output functions are indicated in the following table:
Setting Value
Function Range
0 Running speed 0~Elevator rated speed
1 Reference speed 0~Elevator rated speed
2 Motor running speed
0~2* motor rated synchronous speed
3 Output current 0~2* inverter rated current
4 Output voltage 0~2* inverter rated voltage
5 Output power 0~2* rated power
