CHV180 series frequency inverter special for elevator Detailed function description
.50.
Function
Code
Name Description
Setting
Range
Factory
Setting
P4.07
Magnetic pole
position
amplitude gain
0.50~1.50 0.50~1.50
1.00
P4.08
C phase
magnetic pole
position offset
0~1024 0~1024 512
P4.09
D phase pole
position offset
0~1024 0~1024 512
The above parameters will be updated automatically after autotunning of synchronous
motor; the user can not need to modify it. If the rotating autotuning is not available, this
parameter should be set properly during static autotuning. Please refer to the static
autotuning for detailed information.
Function
Code
Name Description
Setting
Range
Factory
Setting
P4.10
Synchronous
motor static
identification
current
10.0%~100.0% 10.0~100.0
50.0%
The angle is saved as P4.03 after the static autotunning been performed. And the
actual current can display at PB.03, the current of PB.03 should be between
80%~110%. If the current value is smaller obviously, please increase P4.10. If the
actual current is greater, it may report motor autotunning fault (the fault code is TE).
Function
Code
Name Description
Setting
Range
Factory
Setting
P4.11~P4.13
Reserved 0~65536 0~65335
0
6.6 P5 Group--Input terminals
The standard configuration of CHV108 serials frequency has 6 multi-function digital
input terminals and 2 analog input terminals. If need many more input/output terminals,
please choose the corresponding extension card.
