CHV180 series frequency inverter special for elevator Detailed function description

.51.

Function

Code

Name Description

Setting

Range

Factory

Setting

P5.00

Terminal input

mode selection

0~0x3FF 0~0x3FF

The function is to select the switch signal input terminals to be natural open or natural

close. It means terminal input is natural close when the corresponding bit is 1; the

parameter is 16 hex setting. Switch signal corresponding bit is as follows:

BIT9 BIT8 BIT7 BIT6 BIT5

S10 S9 S8 S7 S6

BIT4 BIT3 BIT2 BIT1 BIT0

S5 S4 S3 S2 S1

Function

Code

Name Description

Setting

Range

Factory

Setting

P5.01

Terminal

function input

selection

0: Invalid

1: Valid

0~1 0

The function code is used to set the input channel of the terminal.

0: Communication virtual terminal invalid. The ON-OFF signal is input through the

external terminals.

1: Communication virtual terminal valid. The ON-OFF signal is set by the upper PC

through serial communication.

Function

Code

Name Description

Setting

Range

Factory

Setting

P5.02

S1 Terminal

function

Programmable multifunction

terminal

0~55 1

P5.03

S2 Terminal

function

Programmable multifunction

terminal

0~55 2

P5.04

S3 Terminal

function

Programmable multifunction

terminal

0~40 8

P5.05

S4 Terminal

function

Programmable multifunction

terminal

0~40 9

P5.06

S5 Terminal

function

Programmable multifunction

terminal

0~40 3

P5.07 S6 Terminal Programmable multifunction 0~40 0
