function terminal
P5.08
S7 Terminal
function
Programmable multifunction
terminal
0~40 0
P5.09
S8 Terminal
function
Programmable multifunction
terminal
0~40 0
P5.10
S9 Terminal
function
Programmable multifunction
terminal
0~40 0
P5.11
S10Terminal
function
Programmable multifunction
terminal
0~40 0
This parameter is used to set the corresponding function of the digital multi-function
input terminals.
0：No function
1：Up running (FWD)
2：Down running (REV)
When the running command is controlled by terminal, the elevator’s up and down
commands are controlled by the terminal.
3：Examine running (EXM)
This terminal is used for selecting elevator come into EXM state, this signal works with
up and down running signal, and can control elevator to carry out EXM work.
4：Emergency running (EMER)
This terminal is used to select elevator to come into EMER state，this signal works with
up and down running signal, and can control elevator carry out EXM work.
5：Coast to stop (FSTP)
Inverter blockades output, motor’s stopping process is not controlled by inverter. This
mode has the same meaning as described in P1.29.
6：Fault reset
Exterior fault reset function, is used for far distance failure reset, and has the same
function as STOP/RST key on keyboard.
7：External fault input (EF)
After this signal is available, inverter reports exterior fault (EF) and stop.
8~10：Multi-speed terminals 1~3
The combination of the three terminals can achieve the speed set in 8 steps.
Note: Terminal 1 is for low-speed, terminal 3 is for high-speed.
