INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Detailed function description
.45.
Function
Code
Name Description
Setting
Range
Factory
Setting
P2.10
Motor stator
resistor
0.001~65.535Ω 0.001~65.535
Depend
on model
P2.11
Motor rotor
resistor
0.001~65.535Ω 0.001~65.535
Depend
on model
P2.12
Stator and
rotor
inductance
0.1~6553.5mH 0.1~6553.5
Depend
on model
P2.13
Motor mutual
inductance
0.1~6553.5mH 0.1~6553.5
Depend
on model
P2.14
Motor current
without load
0.01~655.35A 0.01~655.35
Depend
on model
After autotuning, the value of P2.10~P2.14 will be automatically updated.
Note: Do not change these parameters; otherwise it may deteriorate the control
performance of the inverter.
Function
Code
Name Description
Setting
Range
Factory
Setting
P2.15 Reserved 0~65536 0~65536
0
P2.16 Reserved 0~65536 0~65536
0
6.4 P3 Group--Vector control
Function
Code
Name Description
Setting
Range
Factory
Setting
P3.00
ASR low
speed
proportion
gain
0~100 0~100 20
P3.01
ASR low
speed integral
time
0.01~10.00s 0.01~10.00
0.50s
P3.02
Speed
detection low
speed filtrate
times
0~9 0~9 3
