INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Detailed function description
.44.
Function
Code
Name Description
Setting
Range
Factory
Setting
P2.01
W
heel diameter
of traction
motor
100~2000 100~2000
500mm
P2.02 Reduction ratio
1.00~100.00 1.00~100.00
30.00
P2.03
Hoist rope
hanging ratio
1~8 1~8 1
P2.01, P2.02 and P2.03 are parameters of the elevator traction motor, only when
parameters are set correctly, the inverter running-speed can be right parallelism with
elevator’s factual speed. Please refer to P0.02.
Function
Code
Name Description
Setting
Range
Factory
Setting
P2.04
Motor rated
power
0.4~900.0kW 0.4~900.0
Depend
on model
P2.05
Motor rated
frequency
0.01Hz~P0.04 0.01~P0.04
50.00Hz
P2.06
Motor rated
speed
1~36000rpm 1~36000
1460rpm
P2.07
Motor rated
voltage
1~460V 1~460 380V
P2.08
Motor rated
current
0.1~1000.0A 0.1~1000.0
Depend
on model
Note:
 In order to achieve superior performance, please set these parameters
according to motor nameplate, and then perform autotuning.
 The rated power of inverter should match the motors. If the gap is too big,
the control performances of inverter will be deteriorated distinctly.
 Resetting P2.04 can initialize P2.10~P2.14.
Function
Code
Name Description
Setting
Range
Factory
Setting
P2.09
Motor rated
power factor
0.05~1.00 0.05~1.00
0.86
When the inverter cannot perform autotuning, it may optimize motor control
performance by setting the motor rated power factor.
