CHV180 series frequency inverter special for elevator Detailed function description
.65.
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.13
Previous two
fault type
0~31 0~31
Reserved
P7.14
Previous fault
type
0~31 0~31
P7.15
Current fault
type
0~31 0~31
These parameters record three recent fault types. 0 means no fault, 1~31 shows
different fault types.
For details, please refer to description of chapter 8.
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.16
Output
frequency at
current fault
Output frequency at current fault.
P7.17
Output current
at current fault
Output current at current fault.
P7.18
DC bus
voltage at
current fault
DC bus voltage at current fault.
P7.19
Input terminal
state at
current fault
P7.20
Output
terminal state
at current fault
The state of the current fault input terminal is decimal number. Display the state of all digital
input terminals at the latest fault, the sequence is:
BIT9 BIT8 BIT7 BIT6 BIT5
S10 S9 S8 S7 S6
BIT4 BIT3 BIT2 BIT1 BIT0
S5 S4 S3 S2 S1
When the input terminal is ON, its corresponding bit is 1, and the corresponding bit of OFF is 0.
