INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Appendix D
.148.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
time BRAKE
DELAY
P8.07
Brake threshold
voltage
320.0~750.0V 700.0V ○
BRAKE THRE
VOLT
P8.08 Fault auto reset times
0~10 0 ○
AUTO RESET
TIMES
P8.09 Fault relay action
0: Disabled
1: Enabled
1 ○
FAULT
ACTION
P8.10 Reset interval 0.1~100.0s 1.0s ○
RESET
INTERVAL
P8.11
Contacting brake
feedback inspecting
interval
0.1~5.0s 2.0 ◎
BRAKE
FEEDBACK
INTERVAL
P8.12
Contactor feedback
inspecting interval
0.1~5.0s 2.0 ◎
CONTACTOR
FEEDBACK
INTERVAL
P8.13
Stop contracting
brake frequency
0.00~5.00Hz 0.00
P8.14 Start DC brake current0.0~120% 0.0
P8.15 Start DC brake time
0.0~50.0s 0.0
P8.16
Stop brake starting
frequency
0.00~P0.04 0.00
P8.17
Stop brake waiting
time
0.0~50.0s 0.0
P8.18
Stop DC brake current
0.0~120% 0.0
P8.19 Stop DC brake time
0.0~50.0s 0.0
P8.20 Stopping delay 0.0~50.0s 0.0
P8.21
Two/Three-phase
modulation selection
0~1 1
P8.21~P8.
22
Reserved 0~65535 0 ◎
RESERVE
