User manual of EC160 elevator intelligent integrated machine Function parameters
129
4 medium speed up forced speed-changing
switch
24 full load signal
5 no definition 25 overload signal
6 no definition 26 no definition
7 down limit 27 no definition
8 up limit 28 pre-opening feedback
9 emergency electric running 29 pre-opening adhesion
10 inspection signal 30 earthquake
11 inspection up button signal 31 no definition
12 inspection down button signal
32 no definition
13 up door area (rear door opening inspection)
33 open
14 down door area 34 close
15 no definition
35 UPS output signal inspection
16 no definition 36 dual brake travel detection
17 lock elevator signal 37 star-delta output detection
18 contact detection of the drive output
contactor
38 no definition
19 contact detection of the brake contactor 39 no definition
20 brake travel switch detection 40 no definition
Function
code
Instruction Setting range【default value】 Remarks
F0_15 MF output in the car 0~65535【0】
Not modify
in running
Unit: define RDC port of DC01, LED light corresponding to PAS
Ten: define RDO port of DC01, LED light corresponding to DOD
0: closing/opening output light of rear door
1: opening delay light
2: mapping PLC Y5 of I/O board (following output and close of Y5)
3: mapping PLC Y6 of I/O board (following output and close of Y6)
4: low speed opening signal
