User manual of EC160 elevator intelligent integrated machine Running at slow speed
146
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder
parameters
P4 running
comfortability
P5 elevator protection
parameters
P6 communication
setting
P7 drive information
PE factory only
encoder
02 encoder direction
03 low-speed encoder
disconnection detection
time
04 high-speed encoder
disconnection detection
time
05 reverse detection time
of the encoder
06 amplitude gain pole
position
07 C-phase magnetic pole
bias
08 D-phase magnetic pole
bias
09 original position of the
magnetic pole
10 static identification
current
11 pulse counting direction
Function
code
Name Instruction
P0_00 Speed control mode 0-2【1】
P2_00 Motor type 0: AM 1: SM
P2_01
Rated power of the
motor
Depend on the name plate
P2_02
Rated frequency of
the motor
Depend on the name plate
P2_03
Rated speed of the
motor
Depend on the name plate
P2_04
Rated voltage of the
motor
Depend on the name plate
P2_05 Rated current of the Depend on the name plate
