User manual of EC160 elevator intelligent integrated machine Running at slow speed
147
Function
code
Name Instruction
motor
P3_00 Encoder type
0: Incremental encoder (AM)
1: SIN/COS encoder (synchronous 1387)
2: UVW encoder (synchronous 8192)
3: Endat encoder (synchronous 1313)
P3_01
Resolution of the
encoder
1~10000
P3_06
Magnetic pole position
amplitude gain
0.50~1.50 (normal 0.98~1.02)
P3_07
C-phase magnetic
pole bias
0000~9999 (normal 390~400)
P3_08
D-phase magnetic
pole bias
0000~9999 (normal 390~400)
P3_10
Static identification
current
0~150% (depend on the master, generally 40~60)
Enter into the system autotuning menu to select the motor static autotuning.
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
【system autotuning】
[1] hoistway information
autotuning
[2] motor rotating
autotuning
[3] motor static
autotuning
[4] LL weighing
autotuning
[5] FL weighing
autotuning
[6] OL weighing
autotuning
Steps of static
autotuning
1. Check the connection of master UVW, grounding wires, brake and encoder.
2. Connect the safety and door lock circuit and check the parameters setting of
master and encoder in the inspection state.
