User manual of EC160 elevator intelligent integrated machine Installation and wiring
34
stop. After the elevator compresses the buffer according to the national
standards, the switch still keeps acting.
The table above lists the recommended position of corresponding
forced deceleration switch at common speed. The specific conditions
subject to commissioning are closely related to floor height of terminal
stop, starting acceleration curve and effective length of anti-collision
device. For example,
when the anti-collision of the elevator at 1.75m/s is not long enough,
change L1 to 1.2m and L2 to 2.2m;
when the elevator is at 1.0m/s, the bottom floor is 0.7m high and other
floors are 3m high, install 2 deceleration switches at the bottom floor:
L1=0.3m, L2=0.8m and 1 0.8m deceleration switch at the top floor.
If the speed of the elevator is V when it accelerates to the first
deceleration switch by the whole target distance, the distance between
the switch and terminal stop leveling line L=0.61×V
2
+0.2×V.
