INVT EC160

User manual of EC160 elevator intelligent integrated machine Debugging tools
70
Function
code
Name Detailed instruction of parameters
Default
value
U1.14
High bit of input
terminal state
0~65535 Read only
U1.15
Extension input
terminal state
0~65535 Read only
U1.16 Number clearance tip 0~65535 Read only
U1.17
Input terminal state in
the car
0~65535 Read only
U1.18
Output terminal state of
the main board
0~65535 Read only
U1.19
Current feedback
speed of the elevator
0~65535 Read only
U1.20
Running state of the
elevator
0~65535 Read only
U1.21 Output current 0.0~1000.0A Read only
U1.22 Output voltage 0~1000V Read only
U1.23 Output frequency 0.00~999.99Hz Read only
U1.24 Output rotating speed 0~10000rpm Read only
U1.25 Output power 0.0~200.0kW Read only
U1.26 Bus voltage 0.0~1000.0V Read only
U1.27 Torque command -250.0~250.0% Read only
U1.28 Torque compensation -250.0~250.0% Read only
U1.29 Current load 0~10000kG Read only
U1.30
Calculated deceleration
distance
0~60.000m Read only
U1.31
Calculated stopping
distance
0~60.000m Read only
U1.32 Analog input voltage 0~10.0V Read only
U1.33
Extension output
terminal state
0~65535 Read only
U1.34
Terminal output state in
the car
0~65535 Read only
U1.35 DM03 state 0~65535 Read only
