INVT EC160

User manual of EC160 elevator intelligent integrated machine Debugging tools
69
Function
code
Name Detailed instruction of parameters
Default
value
F0.75 Analog LL set voltage 0~65535 0
F0.76 Analog FL set voltage 0~65535 0
F0.77 Analog OL set voltage 0~65535 0
… … … …
F0.99 Reserved 0~65535 0
U0 Group Calling command
U0.00 Manual calling
0~64 refers to the calling of current floors
0 or invalid floor: no operation
0
U0.01 Random running
0~65535 random running
The running times is 10 times of the set value
0
U1 Group System monitoring
U1.00 Running time low bit 0~65535 Read only
U1.01 Running time high bit 0~65535 Read only
U1.02
Total running time low bit
0~65535min Read only
U1.03 Total running time high bit 0~65535min Read only
U1.04
Current elevator
reference speed
0~9999mm/s Read only
U1.05
Reference frequency
monitoring
0.00~400.00Hz Read only
U1.06
Magnetic pole position
angle
0.00~360.00 Read only
U1.07
Static autotuning
detection current
0.0~300.0% Read only
U1.08 C phase sampling 0~1024 Read only
U1.09 D phase sampling 0~1024 Read only
U1.10
Current height of the
elevator
0.00~600.00m Read only
U1.11
Current floor of the
elevator
1~64 Read only
U1.12 Leveling distance 0.000~0.500m Read only
U1.13
Low bit of input terminal
state
0~65535 Read only
