INVT GD100-0R4G-SS2-PV User Manual

Goodrive100-PV series solar pumping inverters Keypad operation procedure
-17-
Serial
No.
Name
Description
LED on means the inverter is in the running
state.
FWD/REV
FED/REV LED
LED off means the inverter is in the forward
rotation state; LED on means the inverter is
in the reverse rotation state.
LOCAL/REMOT
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the inverter is in the
keypad operation state; LED blinking
means the inverter is in the terminals
operation state; LED on means the inverter
is in the remote communication control
state.
TRIP
LED for faults
LED on when the inverter is in the fault
state; LED off in normal state; LED blinking
means the inverter is in the pre-alarm
state.
2
Unit
LED
Mean the unit displayed currently
/
Hz
Frequency unit
RPM
Rotating speed unit
A
Current unit
％
Percentage
V
Voltage unit
3
Display
zone
5-figure LED display displays various monitoring data and alarm code such as
set frequency and output frequency.
Display
Mean
Display
Mean
Display
Mean
Display
Mean
0
1
2
3
4
5
6
7
8
9
A
B
