INVT GD100-0R4G-SS2-PV User Manual

Goodrive100-PV series solar pumping inverters Product overview
-7-
Key
Sign
Description
Remarks
Product
abbreviation
①
Product
abbreviation
GD100 is short for Goodrive100.
Rated power
②
Power range
+ Load type
5R5G—5.5kW
G—Constant torque load
Voltage
degree
③
Voltage
degree
4: AC 3PH 380V(-15%)~440(+10%)
2: AC 3PH 220V(-15%)~240(+10%)
S2: AC 1PH 220V(-15%)~240(+10%)
SS2: AC 1PH input/output 220V(-15%)~
240(+10%)
Protection
level
④
Protection
level
Protection level.
5—IP54
The protection level of a standard inverter
is IP20, but this field is not displayed.
Industrial
code
⑤
Industrial
code
PV stands for solar pumping.
2.4 Product specifications
Model
-SS2
-S2
-2
-4
AC input voltage (V)
220(-15%)~240(+10%)
(1PH)
220(-15%)~240
(+10%) (3PH)
380(-15%)~440
(+10%) (3PH)
Max. DC voltage (V)
440
440
440
800
Start-up voltage (V)
200
200
200
300
Lowest working
voltage (V)
150
150
150
250
Recommended DC
input voltage range
(V)
200~400
200~400
200~400
300~750
Recommended MPP
voltage (V)
330
330
330
550
