INVT GD100-0R4G-SS2-PV User Manual

Goodrive100-PV series solar pumping inverters Function parameters
-41-
Function
code
Name
Detailed illustration of parameters
Default
Modify
temperature
P07.15
MSB of inverter
power
consumption
Display the power used by the inverter.
Inverter power
consumption=P07.15*1000+P07.16
Setting range of P07.15: 0~65535(*1000)
Setting range of P07.16: 0.0~999.9
Unit: kWh
●
P07.16
LSB of inverter
power
consumption
●
P07.27
Current fault type
0:No fault
1:IGBT U phase protection(OUt1)
2:IGBT V phase protection(OUt2)
3:IGBT W phase protection(OUt3)
4:OC1
5:OC2
6:OC3
7:OV1
8:OV2
9:OV3
10:UV
11:Motor overload(OL1)
12:The inverter overload(OL2)
13:Input side phase loss(SPI)
14:Output side phase loss(SPO)
15: Overheat of the boost module (OH1)
16: Overheat fault of the inverter
module(OH2)
17: External fault(EF)
18: 485 communication fault(CE)
19:Current detection fault(ItE)
●
P07.28
Previous fault
type
●
P07.29
Previous 2 fault
type
●
P07.30
Previous 3 fault
type
●
P07.31
Previous 4 fault
type
●
P07.32
Previous 5 fault
type
●
P07.57
Previous 6 fault
type
●
P07.58
Previous 7 fault
type
●
P07.59
Previous 8 fault
type
●
P07.60
Previous 9 fault
type
●
P07.61
Previous 10 fault
type
●
