INVT Goodrive 200A User Manual

Goodrive200A inverters Function parameters
81
Function
code
Name Detailed instruction of parameters
Default
value
Modify
speed 4 speed, selected by the combination of multi-step
terminals 1~4, corresponding to the speed 0 to
speed 15.
When S1=S2=S3=S4=OFF, the frequency input
manner is selected via code P00.06 or P00.07.
When all S1=S2=S3=S4 terminals aren’t off, it
runs at multi-step which takes precedence of
keypad, analog value, high-speed pulse, PLC,
communication frequency input. Select at most
16 steps speed via the combination code of S1,
S2, S3, and S4.
The start-up and stopping of multi-step running is
determined by function code P00.06, the
relationship between S1,S2,S3,S4 terminals and
multi-step speed is as following:
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Step
0
1
2
3
4
5
6
7
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
Setting range of P10.(2n,1<n<17):
-100.0~100.0%
Setting range of
P10.11
The running
time of step 4
0.0s ○
P10.12
Multi-step
speed 5
0.0% ○
P10.13
The running
time of step
5
0.0s ○
P10.14
Multi-step
speed 6
0.0% ○
P10.15
The running
time of step
6
0.0s ○
P10.16
Multi-step
speed 7
0.0% ○
P10.17
The running
time of step
7
0.0s ○
P10.18
Multi-step
speed 8
0.0% ○
P10.19
The running
time of step
8
0.0s ○
P10.20
Multi-step
speed 9
0.0% ○
P10.21
The running
time of step
9
0.0s ○
P10.22
Multi-step
speed 10
0.0% ○
P10.23
The running
time of step
10
0.0s ○
P10.24
Multi-step
speed 11
0.0% ○
P10.25
The running
time of step
11
0.0s ○
P10.26
Multi-step
speed 12
0.0% ○
P10.27
The running
time of step
12
0.0s ○
P10.28
Multi-step
speed 13
0.0% ○
