INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-32-
Function
code
Name
Description
Default
value
Modify
current running stage, and set P10 to select the
current running frequency.
The multi-step speed has the priority when
P00.06 or P00.07 is not equal to 6, but the steps
can only be steps 1–15. The steps are 0–15
when P00.06 or P00.07 is 6.
7: PID control
The running mode of the VFD is process PID
control when P00.06=7 or P00.07=7. It is
necessary to set P09. The running frequency of
the VFD is the frequency value after PID acts.
See P09 for the detailed information of the given
source, given value, feedback source of PID.
8: Modbus communication
The frequency is set by MODBUS
communication. See P14 for detailed
information.
9–11: Reserved
P00.08
B frequency
command
reference
selection
0: Max. output frequency. 100% of B frequency
setting corresponds to the maximum output
frequency.
1: A frequency command. 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
0
○
P00.09
Combination
mode of setting
channels
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max(A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min (A, B): The smaller one between A
0
○
