Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-33-
frequency command and B frequency is the set
frequency.
Note: The combination mode can be shifted by
P05 (terminal function).
Frequency set
through keypad
When A and B frequency commands select the
keypad for setting, the value of the function code
is the original setting one of the frequency data
of the VFD.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
ACC time means the time needed if the VFD
speeds up from 0Hz to the max. output
frequency (P00.03).
DEC time means the time needed if the VFD
speeds down from the max. output frequency
(P00.03) to 0Hz.
Goodrive18 series VFD has four groups of
ACC/DEC time, which can be selected by P05.
The factory default ACC/DEC time of the VFD is
the first group.
Setting range of P00.11 and P00.12: 0.0–
3600.0s
0: Run at the default direction. The VFD runs in
the forward direction. FWD/REV indicator is off.
1: Run at the opposite direction. The VFD runs in
the reverse direction. FWD/REV indicator is on.
Modify the function code to shift the rotation
direction of the motor. This effect equals to the
shifting the rotation direction by adjusting either
two of the motor lines (U, V and W). The motor
rotation direction can be changed by
QUICK/JOG on the keypad. Refer to parameter
P07.02.
Note: When the function parameter is restored
to the default value, the motor’s running direction
is restored to the default one. Use this function
