INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-42-
Function
code
Name
Description
Default
value
Modify
standard motor configuration of
the VFD. If the power of the
motor is greatly different from
that of the standard motor
configuration, the control
performance of the VFD
degrades significantly.
Note:
Resetting the rated power of
the motor (P02.01) can
initialize the parameters of
P02.02 to P02.10.
P02.06
Stator resistor of
AM
0.001–65.535Ω
After motor parameter
autotuning is properly
performed, the values of
P02.06 to P02.10 are
automatically updated. These
parameters are the reference
parameters for
high-performance vector
control, directly affecting the
control performance.
Note:
Do not modify these
parameters unless it is
necessary.
Model
depended
○
P02.07
Rotor resistor of
AM
0.001–65.535Ω
Model
depended
○
P02.08
Leakage
inductance of
AM
0.1–6553.5mH
Model
depended
○
P02.09
Mutual
inductance of
AM
0.1–6553.5mH
Model
depended
○
P02.10
Non-load
current of AM
0.1–6553.5A
Model
depended
○
P02.11
Magnetic
saturation
coefficient 1 for
the iron core of
AM
0.0–100.0%
80.0%
◎
P02.12
Magnetic
saturation
coefficient 2 for
the iron core of
AM
0.0–100.0%
68.0%
◎
P02.13
Magnetic
0.0–100.0%
57.0%
◎
