Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-46-
Function
code
Name
Description
Default
value
Modify
1: Keypad (P03.12)
2: Reserved
3: Analog AI2
4: Analog AI3
5: Reserved
6: Multi-step speed
7: Modbus communication
8–10: Reserved
Note: Setting mode 2–7, 100% corresponds to 3
times of the motor rated current
Note: For setting methods 2–7, 100%
corresponds to 3 times the motor rated current.
P03.12
Torque set
through keypad
Setting range: -300.0%–300.0% (of the motor
rated current)
50.0%
○
P03.13
Torque given
filter time
0.000–10.000s
0.100s
○
P03.14
Setting source
of forward
rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16 sets P03.14, P03.17 sets
P03.15)
1: Reserved
2: AI2
3: AI3
4: Reserved
5: Multi-step speed
6: Modbus communication
7–9: Reserved
Note: For setting methods 1–9, 100%
corresponds to the maximum frequency
0
○
P03.15
Setting source
of reverse
rotation
upper-limit
frequency in
torque control
0
○
P03.16
Forward rotation
upper-limit
frequency set
through keypad
in torque control
The function codes are used to set the frequency
upper limits. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00 Hz
○
P03.17
Reverse rotation
upper-limit
frequency set
through keypad
50.00 Hz
○
