INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-47-
Function
code
Name
Description
Default
value
Modify
in torque control
P03.18
Setting source
of electromotion
torque upper
limit
The function codes are used to select the
sources for setting electromotion and braking
torque upper limits.
0: Keypad (P03.20 sets P03.18 and P03.21 sets
P03.19)
1: Reserved
2: AI2
3: AI3
4: Reserved
5: Modbus communication
6–8: Reserved
Note: For setting methods 1–8, 100%
corresponds to three times the motor current.
0
○
P03.19
Setting source
of braking
torque upper
limit
0
○
P03.20
Electromotion
torque upper
limit set through
keypad
This function code is used to set the torque limit.
Setting range: 0.0–300.0% (of the motor rated
current)
180.0%
○
P03.21
Braking torque
upper limit set
through keypad
180.0%
○
P03.22
Weakening
coefficient in
constant power
zone
Used when the motor is in weakening control.
The function codes P03.22 and P03.23 are valid
at constant power. The motor will enter the
weakening state when the motor runs at the
rated speed. Change the weakening curve by
modifying the weakening control coefficient. The
bigger the weakening control coefficient is, the
steeper the weak curve is.
0.3
○
P03.23
Lowest
weakening point
in constant
power zone
20%
○
