Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-61-
Function
code
Name
Description
Default
value
Modify
7: Frequency level test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Set counting value arrival
19: Designated counting value arrival
20: External fault valid
21: Reserved
22: Running time arrival
23: Modbus communication virtual terminal
output
2425: Reserved
26: Establishment of DC bus voltage
2730: Reserved
P06.05
Polarity
selection of
output terminals
This function code is used to set the pole of the
output terminal.
When the current bit is set to 0, the input terminal
is positive.
When the current bit is set to 1, the input terminal
is negative.
BIT3
BIT2
BIT1
BIT0
Reserved
Reserved
RO2
RO1
Setting range: 0F
0
P06.10
RO1 switching
on delay time
The function codes define the corresponding
delay time of the electrical level change when
the programmable terminals are switched on and
off.
0.000s
P06.11
RO1 switching
off delay time
0.000s
P06.12
RO2 switching
on delay time
0.000s
