INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-65-
Function
code
Name
Description
Default
value
Modify
1: Lock all keys
2: Lock only PRG/ESC
P07.03
Running
command
channel
switchover
sequence of
QUICK/JOG
When P07.02=6, set the switchover sequence of
running command channels.
0: Keypad control→Terminals control→
Communication control
1: Keypad control←→Terminal control
2: Keypad control←→Communication control
3: Terminal control←→Communication control
0
○
P07.04
Stop function
selection of
STOP/RST
This function code is used to select the stop
function validity of STOP/RST. For fault reset,
STOP/RST is valid at any state.
0: Valid only for keypad control
1: Valid both for keypad and terminal control
2: Valid both for keypad and communication
control
3: Valid for all control modes
0
○
P07.05
Displayed
parameter
selection 1 in
running state
0x0000–0xFFFF
BIT0: running frequency (Hz on)
BIT1: set frequency (Hz blinking)
BIT2: bus voltage (Hz on)
BIT3: output voltage (V on)
BIT4: output current (A on)
BIT5: running rotation speed (rpm on)
BIT6: output power (% on)
BIT7: output torque (% on)
BIT8: PID reference value (% blinking)
BIT9: PID feedback value (% on)
BIT10: input terminal state
BIT11: output terminal state
BIT12: torque setting (% on)
BIT13: pulse counting value
BIT14: reserved
BIT15: PLC and the current step of multi-step
speed
0x03FF
○
P07.06
Displayed
parameter
0x0000–0xFFFF
BIT0: AI1 value (V on)
0x0000
