INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-66-
Function
code
Name
Description
Default
value
Modify
selection 2 in
running state
BIT1: AI2 value (V on)
BIT2: AI3 value (V on)
BIT3: reserved
BIT4: motor overload percentage (% on)
BIT5: the VFD overload percentage (% on)
BIT6: ramp frequency given value (Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9–15: reserved
P07.07
Displayed
parameter
selection in
stopped state
0x0000–0xFFFF
BIT0: set frequency (Hz on, frequency blinking
slowly)
BIT1: bus voltage (V on)
BIT2: input terminal state
BIT3: output terminal state
BIT4: PID reference value (% blinking)
BIT5: PID feedback value (% blinking)
BIT6: torque reference (% blinking)
BIT7: reserved
BIT8: analog AI2 value (V on)
BIT9: analog AI3 value (V on)
BIT10: reserved
BIT11: PLC and the current step of multi-step
speed
BIT12: pulse counting value
BIT13–BIT15: reserved
0x00FF
○
P07.08
Frequency
display
coefficient
0.01–10.00
Displayed frequency = Running frequency *
P07.08
1.00
○
P07.09
Speed display
coefficient
0.1–999.9%
Mechanical rotation speed = 120 * Displayed
running frequency * P07.09/Motor pole pairs
100.0%
○
P07.10
Linear speed
display
coefficient
0.1–999.9%
Linear speed = Mechanical rotation speed *
P07.10
1.0%
○
P07.11
Rectifier bridge
module
-20.0–120.0°C
●
