SMDI Protocol
There are three types of SMDI messages. Within each message is an “Action Code”, which
defines the function or required action of the AA/VM system. Fields within the messages also
define the called/calling station and station status. The various message types and definition of
the fields are shown in the chart below.
Type I message
cr lf MD ggg mmmm a xxxxxxxxx sp yyyyyyyyy sp cr lf^Y
Type II message
cr lf MD ggg mmmm a xxxxxxxxx sp sp cr lf^Y
Type III message
cr lf MD ggg mmmm a sp yyyyyyyyy sp cr lf^Y
Field
Description
cr
carriage return
lf
line feed
MD
Message Desk
ggg
Message desk number, AA/VM system, default
001
mmmm
Message Desk terminal, 0001-9999, VM port
a
action code
xxx...x
called station number or station calling the VM
group
yy…y
calling station number
sp
ASCII space character
^Y
end of SMDI message, control + Y (0x19)
The following table provides detailed information on the meaning and function of the various
SMDI messages used.
Table 2.38.3-1 SMDI Messages
Action
Code
Reason
Purpose
In-band code
Message
Type
SMDI
Message MD
001 0001-
A
Unconditional forward to VM
Put Mail
P#
II
A xxxxx yyyyy
B
Called Station busy
Busy Mail
P#3P
II
B xxxxx yyyyy
C
Disconnect, connected party
disconnect
*****
II
C xxxxx yyyyy
D
Direct Fwd to VM group
Get Mail
P##
II
D xxxxx yyyyy
E
Error, invalid number
Error
P#*5P
II
E xxxxx yyyyy
H
Two-way Record
record
None
II
H xxxxx yyyyy
I
DND
DND
P#*6P
II
I xxxxx yyyyy
N
No Answer
No Answer
P#*4P
II
N xxxxx yyyyy
R
Direct CO/IP ring to VM group
AA
None
III
R xxxxx yyyyy
