iPECS-LIK
Feature Description & Operation Manual Issue 6.0d1
168
Programming
CO/IP
1 Metering Type (PGM 142-Btn 3)
SYSTEM
1 SMDR Cost per Unit Pulse (PGM 177-Btn 10)
2 SMDR Decimal (PGM 177-Btn 11)
3 SMDR Start Timer (PGM 177-Btn 12)
4 CO Warning Tone Timer (PGM 180-Btn 19)
Related Features
 SMDR (Station Message Detail Recording)
 Lost Call Recording
 Traffic Analysis
 CO/IP Call Warning Tone Timer
Hardware
 RS-323 device to capture SMDR
2.68.2 SMDR Call Records
Description
SMDR (Station Message Detail Recording) provides detailed information on incoming and
outgoing calls. Assignable options in the system database permit recording of all external calls,
all external outgoing calls or toll calls, calls that exceed a fixed duration and intercom calls. Call
records are output either upon completion of the call (real-time) or in response to a request
from the System Attendant. SMDR may be sent periodically via e-mail to a defined e-mail
address.
The SMDR record output for external calls is as shown in the figure below. There are two
flexible fields, Field I and Field II. Each Field is defined to show Ring duration, CLI (Caller Id) or
CPN (Called Party Number).
NO
STA
CO
TIME
START
DIAL/CLI/CPN
NUM-1
COST
ACCOUNT
CODE
DIAL/CLI/CPN
NUM II
DC
XXXX
SSSS
BBB
DD:DD
FF/FF/FF
EE:EE
HCCCCCCCCCC
CCCCCCCC
sssss
Aaaaaaaa
aaaa
Hccccccccccc
ccccccc
rr
The various fields or items for a Call Record are:
NO
SMDR record number, optional output, (PGM 177-Btn 23)
STA
3 or 4 digit station number
CO
2 or 3 digit CO Line number
Time
Call duration in minutes and seconds
Start
Date and time call was placed/received
NUM I
Flex Field I, for outgoing call displays dialed number, for incoming call
displays Ring duration, CLI or CPN (PGM 177-Btn 20)
Cost
Cost of Call
Account Code
Account code entered for call
