Feature Description & Operation Manual Issue 6.0d1
409
8.3 MAKE CALL
Description
There are three types of call setup – Station Call, CO Call, System Call Feature Implementation.
Operation
Making Station Call Setup
1. Dial Station Number.
2. If ‘Dial Digit Map’ is programmed, SIP Phone will send call setup immediately.
3. If ‘Dial Digit Map’ is not programmed, press the [SEND] button or “#” key for send
out call setup.
Making CO Call Setup
1. CO Access Code + Dial Number + [SEND]
ex) CO Access Code “9”, Dial Number ‘450-4500’,
dial ‘94504500’ and press [SEND] or “#” button
NOTE
If you program ‘Second Dial Tone Digit Map’ on SIP Phone, you will hear self dial tone
from SIP Phone.
2. CO Access Code + [SEND],
after hearing CO dial tone, press Dial Number
ex) CO Access Code “9”, Dial Number ‘450-4500’,
dial “9” and press [SEND] or “#”
hear CO dial tone from system
dial ‘4504500’
Making System Call Feature Setup
1. System Call Feature by Numbering Code : System Numbering Plan (PGM106-109)
2. Enblock Dialing : System Call Feature numbering code + data + [SEND] button.
3. Supported Call Features by Numbering are,
Internal Page Zones
Internal All Call Page
Meet Me Page
Internal All Call Page
Meet Me Page
Internal All Call Page
External Page Zone
External All Call Page
All Call Page
SMDR Account Code Enter
SLT Last Number Redial
Do-Not-Disturb(DND)
Call Forward
Speed Dial Program
